Pure Food Grade Polypropylene Industrial Filter Press For Liquid Solid Separation

Name: Pure Food Grade Polypropylene Industrial Filter Press For Liquid Solid Separation
Brand: Xin Ming
Price: 1 USD

Buy cheap Pure Food Grade Polypropylene Industrial Filter Press For Liquid Solid Separation product

Brand Name : Xin Ming

Model Number : BA(M)Q20/630-25

Certification : ISO9001, CE

Place of Origin : Made in China

MOQ : 1 Sets

Price : Negotiable

Payment Terms : T/T, Western Union, D/P

Supply Ability : 10000 Sets/per Year

Delivery Time : Within 25-35 working days after receive 30% deposit

Packaging Details : Standard Packing

Material : PP, Steel

Voltage : 380V/220V/400V, Customized

Dimension(L*W*H) : 2750*1150*1100(mm)

Type : Hydraulic Filter Press

Function : Liquid Solid Separation,Dewatering

Filter Pressure : ≥0.6MPa

Application : Beverage/Food/Beer/Pharmacy/Fine Chemical

Filter Area : 20M2

Filter Clothes : PP

Cake Thickness : ＞25mm

Weight : 3300kg

Life time : 3~5years

Contact Now

Pure Food Grade Polypropylene Making the Blood Industry Filter Press

Pure Food Grade Polypropylene Industrial Filter Press For Liquid Solid Separation

630 Manual or Automatic Hydraulic Filter Press

Manual or Automatic hydraulic filter press equipped with screw jack for driving the pressing system.Simplified structure,no need power supply,economy,normally suitable for 1-40m2 filtration area.

Holding pressure by electro connecting pressure gauge,convenientoperation,steady,reliable structure,suitable for middle class of filtration area.

Due to the manual operation, this type of filter press is use in low frequencyy and less filter plate working condition.

Technical Data

Model	BA(M)Q20/630-25
Filter Area(m2)	20
Plate Size(mm)	630*630
Cake Thickness(mm)	＞25
Filter Chamber Volume(L)	298
Plate Qty(pcs)	24
Frame Qty(pcs)	25
Filtration Pressure(MPa)	≥0.6
Weight(kg)	3300
Dimensions LWH(mm)	275011501100
Foundation Size L/B/D/H(mm)	2270/400/1000/820/565

Feature

1.Simplified structure

2.No need power supply

3.Solid&liquid separation

4.Suitable for 20 m2 filtration area

Fine chemical of industries,food, beverage,beer,sugaring...

Application

Pigment&dye pharmacy chemical
suitable for industries of middle class of filtration area

Pure Food Grade Polypropylene Industrial Filter Press For Liquid Solid Separation

Dewatering rollers are arranged in scientific way.Filtrate is respectively discharged from gravity zone,wedge-shaped zone and squeezing zone without disturbing each other.Dewatering rollers has larger diameter and better dewatering effect, they endowed belt filter with high treatment capacity, high efficiency and energy saving.

Our Service

Pure Food Grade Polypropylene Industrial Filter Press For Liquid Solid Separation

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Maintenance, warranty.

Chengdu Xinming Environmental Protection Co., Ltd is a professional equipment manufacturing enterprises , specialized in design ,manufacture and sales of various filtration equipment as well as comprehensive filtration solutions and projects. We have a sound quality assurance system and advanced testing equipment ,can be from raw material into the factory warehousing , processing , assembly , to the whole machine factory supervision and control throughout the process . we have the high-class R&D personnel , experienced workers and high qualified sales team , we are devoting to provide best products for our clients.
